Description
Grid Tied Inverters are powerful inverters that convert direct current (DC) electricity into alternating current (AC), It is also called a grid-connected or on-grid solar system that works without a battery. The Main purpose of Grid tied inverter is to supply Solar power generated from PV Panels to Homes and unused power to Grid.
Features
-
- 1 MPP tracker, Max. efficiency up to 97.5%
- Zero export application,VSG application
- String intelligent monitoring (optional)
- Wide output voltage range
- Anti-PID function(Optional)
-
Low start-up voltage of 80V
Key Technical
|
Model Name |
SUN-2.5K-G04 P1-EU-AM1 |
| Rated AC Output Power |
3 kW |
|
Solar PV Input3.3 |
kW |
|
Efficiency |
97.3% |
|
Feed-in Phase |
Single-phase |
|
Topology |
Transformerless |
|
Number of MPPT |
1 |
|
Noise |
< 30dBA |
|
Weight (kg) |
4.8 Kg |
|
Dimensions [L * H * W] mm |
280Wx272.5Hx184D |
User Manual: Download product data sheet to know detailed electrical parameters
