The Bharatcell 120V 100Ah Lithium Battery is engineered to deliver reliable and efficient energy storage for modern power systems. With a total capacity of 12kWh, this high-voltage lithium battery provides stable output and superior performance for residential, commercial, and industrial applications.
Powered by LiFePO₄ cell chemistry, the battery offers enhanced safety, longer lifecycle, and better thermal stability compared to traditional lead-acid batteries. The integrated Smart Battery Management System (BMS) ensures multi-layer protection including:
Overcharge Protection
Over-discharge Protection
Short-circuit Protection
Over-current Protection
Temperature Monitoring
Cell Balancing
Its modular design allows system scalability for larger energy storage setups, making it ideal for solar hybrid inverters and high-voltage applications.
📊 Technical Specifications Table
Specification
Details
Brand
Bharatcell
Battery Type
Lithium Iron Phosphate (LiFePO₄)
Nominal Voltage
120V DC
Rated Capacity
100Ah
Energy Capacity
12kWh
Cycle Life
4000 Cycles @ 80% DoD
Charging Method
CC / CV
BMS
Integrated Smart BMS
Communication (Optional)
CAN / RS485
Operating Temp (Charge)
0°C to 55°C
Operating Temp (Discharge)
-20°C to 60°C
Installation Type
Rack / Floor Mount
Application
Solar ESS, UPS, Telecom, Industrial Backup
⭐ Key Features & Highlights
✅ High Energy Output: 12kWh (120V × 100Ah) ✅ Advanced LiFePO₄ Technology – Safer & longer life than lead-acid ✅ 4000+ Deep Cycles – Extended lifespan ✅ Smart Built-in BMS – Overcharge, short-circuit & temperature protection ✅ Fast Charging Capability ✅ Maintenance Free Operation ✅ Wide Temperature Range Performance ✅ Ideal for Solar, Hybrid Inverter, UPS & Industrial Applications
