Deye 8Kw Smart Solar Hybrid Transformer Less Inverter
Deye 8Kw Smart Solar Hybrid Transformer Less Inverter
No reviews
Regular price
Rs. 231,412.00
Regular price
Rs. 245,520.00
Sale price
Rs. 231,412.00
Unit price
/
per
Couldn't load pickup availability
- Deye 8KW Smart Solar Hybrid Transformer Less Inverter SUN 8K-SG is a brand new three-phase hybrid inverter with a low battery voltage of 48V, ensuring the system is safe and reliable. With a compact design and high-power density, this series supports a 1.3 DC/AC ratio, saving device investment. It supports three-phase unbalanced output, extending the application scenarios. Equipped with CAN port (x2) BMS and parallel, x1 RS485 port for BMS, x1 RS232 port for remotely control, x1 DRM port, which makes the system smart and flexible.
- Remotely shutdown function Smart Monitoring Platform
- Thanks to the smart monitoring platform, Deye full series inverter products support remotely shut down immediately when the accident occurs. Setting parameters and FW update remotely, which makes PV plant O&M easier.
- 48V low voltage battery, transformer isolation design
- 6 time periods for battery charging/discharging
- Max. charging And discharging current of 240A
- Frequency droop control, Max.16pcs parallel
- DC couple and AC couple to retrofit existing solar system
- Support storing energy from diesel generator
- Supports three-phase unbalanced output
- Unique Smart Load application and Grid peak-shaving function
Product Details:
| Capacity | 8 kw |
| Brand | Deye Inverters |
| Model | SUN-8K-SG04LP3-EU |
| Grid Type | Hybrid Inveter |
| Input Voltage | 550 (160~800) String Input |
| Max Supported Panel Power | 10400 kw |
| Warranty | 5 Years |
Need More Details Check Product Brochure
Deye Inverters has unique features called Zero Export Application which is inbuilt into the Inverters. So it will help to start without net metering.
Features
Zero export application, VSG application
Low start-up voltage
Remote change of operating parameters
Remote software upload
String intelligent monitoring (optional)
Ac voltage range can be change up to 300V (1 Phase)
Deye Inverters are very easy to operate because of switches. Also it is a plug and play kind of Inverters so not require any king setting on it..
Starting voltage for Deye Inverters for DC side is 80V for Single Phase
Deye Inverters has 5 Years of Standard warranty.
