UTL Lithium Ion (LiFePO4/LFP) Battery 120V/100Ah ā SM
UTL Lithium Ion (LiFePO4/LFP) Battery 120V/100Ah ā SM
Couldn't load pickup availability
The UTL ULIBES-120V 100Ah (LP100-SM) is a premium LiFePO4 Lithium Battery designed for high-voltage solar energy storage applications, commercial backup solutions, and industrial-grade inverter systems. Built with advanced Lithium Iron Phosphate (LiFePO4) chemistry, this battery offers superior safety, long operational life, and high power efficiency compared to conventional lead-acid or tubular batteries.
With a massive 12 kWh usable energy capacity, the ULIBES-120V lithium battery is engineered for applications requiring long backup, fast charging, and stable energy delivery. Its integrated Smart BMS (Battery Management System) provides multi-layer protection against overcharge, deep discharge, overcurrent, overheating, and short circuits, ensuring maximum reliability and extended lifecycle performance.
Ideal for 120V MPPT solar PCUs, hybrid solar inverters, telecom systems, commercial offices, industrial UPS, and high-capacity off-grid power plants, this battery is maintenance-free, lightweight for its class, and built for uncompromising durability.
š Key Features
ā Massive 12 kWh energy storage for commercial & off-grid systems
ā Smart BMS offers top-tier safety & battery health monitoring
ā Fast charging with high efficiency
ā 3500 cycle life ensures long-term savings
ā Works perfectly with 120V MPPT & hybrid PCUs
ā Maintenance-free and eco-friendly
ā Highly stable even in high-temperature Indian climate
š Technical Specifications ā UTL ULIBES-120V100AH-LP100-SM
| Specification | Details |
|---|---|
| Model | ULIBES-120V100AH-LP100-SM |
| Battery Type | LiFePO4 (Lithium Iron Phosphate) |
| Nominal Voltage | 120V |
| Rated Capacity | 100Ah |
| Total Energy Capacity | 12 kWh |
| Usable Capacity | ~95% (as per BMS settings) |
| Recommended System Voltage | 120V Solar/Hybrid PCU |
| Cycle Life | 3500 cycles |
| Design Life | 10+ Years |
| Charging Method | CC/CV ā Fast Charging Supported |
| Max Charging Current | Controlled by Smart BMS |
| Max Discharging Current | As per BMS limits |
| BMS Protection | Overcharge, Over-discharge, Over-current, Short Circuit, Over-temperature, Cell Balancing |
| Operating Temperature (Charge) | 0Ā°C to 55Ā°C |
| Operating Temperature (Discharge) | ā20Ā°C to 60Ā°C |
| Storage Temperature | ā10Ā°C to 45Ā°C |
| Self-discharge Rate | <3% per month |
| Communication Interface | (Varies by model ā CAN/RS485 if applicable) |
| Applications | High-voltage Solar PCUs, Hybrid Inverters, Telecom, Industrial UPS, Commercial Power Backup |
| Maintenance | 100% Maintenance-Free |
| Safety Features | Fire-safe LiFePO4, Shock-resistant, Deep discharge protection |
| Warranty | Manufacturer Warranty (varies by seller) |
-
